Kleemann MR 110 Z

Feeding unit Feed capacity up to approx. (t/h) 350 Max. feed size (mm) 880 x 550 x 330 Feed height (with extension) (mm) 4,190 (4,550) Hopper volume (with extension) (m³) 4.4 Width x length (with extension) (mm) 2,100 x 3,700 (2,800 x 3,700) Vibrating feeder Width x length (mm) 900 x 2,600 Prescreening Type Double-deck heavy-piece screen Width x length (mm) 1,010 x 2,100 Side discharge conveyor (optional) Width x length (extended) (mm) 650 x 4,000 (6,000) Discharge height approx. (extended) (mm) 2,900 (3,650) Crusher Impact crusher type SHB 110-080 Crusher inlet width x height (mm) 1,100 x 800 Crusher weight approx. (kg) 13,000 Rotor diameter (mm) 1,100 Crusher drive type, approx. (kW) direct, 310 Adjustment of impact toggles infinitely variable, fully hydraulic Crushing capacity with demolished concrete up to approx. (t/h) 240 Crushing capacity with rubble up to approx. (t/h) 240 Crushing capacity with broken asphalt up to approx. (t/h) 205 Crushing capacity with limestone up to approx. (t/h) 265 Discharge chute Width x length (mm) 1,200 x 2,400 Crusher discharge conveyor Width x length (mm) 1,200 x 9,300 Crusher discharge conveyor Discharge height approx. (mm) 3,550 Power supply unit Drive concept diesel-direct Drive output of Scania diesel engine (kW) 365 – 371 Generator (kVA) 135 Post screening unit (optional) Single-deck post screening unit > Width x length (mm) 1,350 x 4,550 > Discharge height of fine grain discharge conveyor approx. (mm) 3,490 Double-deck post screening unit > Width x length (mm) 1,350 x 4,550 > Discharge height of fine grain discharge conveyor approx. (mm) 3,430 Return conveyor (mm) 500 x 9,100 Transport Transport dimensions without options > Transport height (mm) 3,600 > Transport length approx. (mm) 17,340 > Max. transport width (mm) 3,000 Transport dimensions with post screening unit > Transport length with single-deck post screening unit (mm) 21,110 > Transport length with double-deck post screening unit (mm) 21,750 > Transport width with screening unit (mm) 3,050 Transport weight > Transport weight single-deck post screening unit (kg) 6,100 > Transport weight double-deck post screening unit (kg) 8,400 > Transport weight of basic plant – max. configuration (kg) 44,500 – 60,500
