Cummins KTA19-P700

توربيني

Engine model KTA19-P700 Engine type 6 cylinders in line Displacement 18.9 L Rated Power (KW@RPM) 522 kW/700 HP @ 1500 rpm Peak Torque(Nm@RPM) 2769 N.m @ 2042 rpm Emission Standard Euro 2 Cummins diesel engine KTA19-P700 Technique Specification Bore*stroke 159mm*159mm Intake method Turbochager&Intercooled Fuel systeme Direct Injection Pump Cooling method Fluid Cooling Governor Type Mechanical Control Compression Ratio 13.9 : 1 Fuel Consumption: 210 g/Kw.h Starting System Electrical Starting Motor 12V/24V Lowest Starting Temp .(without auxiliary system) -12℃ Cummins diesel engine KTA19-P700 Trade Information Warranty time 1year or 1500h Engine Size(L*W*H): 2151mm*966mm*1704mm Packing size 2451mm*1300mm*2000mm Weight net 2073Kg Weight gross 2123 Kg Delivary port Shanghai Delivary time 15 working days Trade termes FOB/CIF/CNP Payement termes T/T，L/C All the spare parts for Cummins KTA19-P700 are available;
